Jasic Plasma Cut 101 Inverter Plasma Cutter Package

The Jasic Plasma Cut 101 is professional high-end cutting inverter equipped with the latest IGBT technology.
Brand: JASIC
Manufacturer part number: JP-101

The Jasic Plasma Cut 101 is professional high-end cutting inverter equipped with the latest IGBT technology.

This technologically advanced plasma inverter is extremely user-friendly and offers reliable cutting performance.

The machine provides variable cutting control that allows the operator to produce precise smooth cuts

Key Features

  • IGBT plasma cutting inverter

  • Lightweight, portable modern design

  • Variable cutting control

  • Non HF ignition

  • Supplied with the PT100 6m plasma torch

  • LED display

  • Smooth precise cutting

  • Simple operation

  • CNC Interface fitted as standard

Package Includes

PT100 Plasma Torch, Work Return Lead and Clamp, Trolley

Fact Sheet

Jasic Pro Plasma Cut 101 Inverter Package Fact Sheet

£3,628.80 incl VAT
£2,540.16 incl VAT
increase decrease
Availability Date: 1-3 Days

The Jasic Plasma Cut 101 is professional high-end cutting inverter equipped with the latest IGBT technology.

This technologically advanced plasma inverter is extremely user-friendly and offers reliable cutting performance.

The machine provides variable cutting control that allows the operator to produce precise smooth cuts

Key Features

  • IGBT plasma cutting inverter

  • Lightweight, portable modern design

  • Variable cutting control

  • Non HF ignition

  • Supplied with the PT100 6m plasma torch

  • LED display

  • Smooth precise cutting

  • Simple operation

  • CNC Interface fitted as standard

Package Includes

PT100 Plasma Torch, Work Return Lead and Clamp, Trolley

Fact Sheet

Jasic Pro Plasma Cut 101 Inverter Package Fact Sheet

Products specifications
Attribute nameAttribute value
Plasma Cutters
Input voltageAC 400V - 50/60 Hz
Leff17A
Input Power (kVA)18.8
Current range20 - 100A
Cutting Capacity (Clean)30mm
Cutting Capacity (Severance)35mm
Efficiency85%
Power factor0.99
Protection classIP21S
Insulation classF
Compressed Air Requirement220 Ltr/Min @ 5 Bar (73 psi)
Dimensions LxWxH568 x 259 x 446mm
Weight27kg
*
*
*
Products specifications
Attribute nameAttribute value
Plasma Cutters
Input voltageAC 400V - 50/60 Hz
Leff17A
Input Power (kVA)18.8
Current range20 - 100A
Cutting Capacity (Clean)30mm
Cutting Capacity (Severance)35mm
Efficiency85%
Power factor0.99
Protection classIP21S
Insulation classF
Compressed Air Requirement220 Ltr/Min @ 5 Bar (73 psi)
Dimensions LxWxH568 x 259 x 446mm
Weight27kg
